科技论文和展示

这里您可以找到在全球 COMSOL 年会上所有用户报告的演示文稿。这些演示文稿介绍 COMSOL 用户是如何使用 COMSOL Multiphysics 进行创新性研究和产品设计。研究主题涵盖了包括电气、机械、流体和化工等范围广泛的行业和应用领域。请使用“快速搜索”来查找与您的研究领域相关的演示文稿。

3D Electromagnetic Field Simulation in Microwave Ovens: A Tool to Control Thermal Runaway

T. Santos[1], L.C. Costa[1,2], M. Valente[1,2], J. Monteiro[1,2], and J. Sousa[3]
[1]University of Aveiro, Portugal
[2]I3N, Aveiro, Portugal
[3]TEKA Portugal S.A., Ílhavo, Portugal

In microwave heating applications, the energy is introduced directly into the volume of the material and as consequence the quality of the process is highly dependent on the uniformity of the electromagnetic field distribution along it. That is, the non uniformity of the heating is a potential problem with serious consequences. Thermal runaway is the most critical, in materials with temperature ...

Simulations of Negative Curvature Hollow-core Fiber - new

J. Zhang[1], Z. Wang[1], J. Chen[1]
[1]College of Optoelectronic Science and Engineering, National University of Defense Technology, Changsha, Hunan, China

COMSOL Multiphysics® software was used to simulate and analyze the transmission attenuation spectra of the negative curvature hollow-core fiber (NCHCF) over the wavelength from 2.7 μm to 4.2 μm. The effect of thickness of capillaries and the effect of the distance between the capillaries on confinement loss spectra were studied, which agreed well with the high-loss and low-loss bands predicted ...

Calculating the Capacitance of Shielded Microstrip Lines

S. M. Musa, and M. N. O. Sadiku
College of Engineering, Prairie View A&M University, Prairie View, TX, USA

This paper presents a numerical analysis for calculating the capacitance of singlestrip and double-strip shielded transmission lines. Modeling and simulation of the capacitance of shielded microstrip lines using COMSOL are illustrated. We determined the capacitance per unit length of each shielded microstrip line.We compared our results with those obtained by other methods and found them to be in ...

Calculation of Capacitances of Symmetrical Triple Coupled CPW Transmission Lines and Multilayer CPW Broadside Coupled Lines Balun

S. Musa[1], M. N. O. Sadiku[1]
[1]Prairie View A&M University, Prairie View, TX, USA

The accurate estimate of values of electromagnetic parameters are essential to determine the final circuit speeds and functionality for designing of high-performance integrated circuits and integrated circuits packaging. In this paper, the quasi-TEM analyses of symmetrical triple coupled Coplanar Waveguide (CPW) transmission lines and multilayer CPW broadside coupled-line balun are successfully ...

Simulating the Generation and Guided Propagation of Terahertz Radiation using COMSOL Multiphysics

Jason A. Deibel
Rice University

Electromagnetic waves within the Teraherz frequency spectrum are common in medical techonolgy applications, such as imaging, spectroscopy and drug detection. In this presentation, we explain how Teraherz Radiation is used in different applications, how to produce Electromagnetic waves in the Teraherz frequency, and how to analyze them. Simulations in COMSOL Multiphysics are included as ...

Virtual Prototype of a Dielectric Window for High-Power Microwave Tubes - new

A. Leggieri[1], D. Passi[1], F. di Paolo[1]
[1]Dipartimento di Ingegneria Elettronica, Università degli Studi di Roma Tor Vergata, Rome, Italy

This paper describes the Virtual Prototype of a Dielectric Window or High Power Microwave Vacuum Tubes and Linear Accelerators. Design formulas are provided and Computer Aided Design techniques based on COMSOL Multiphysics® software are proposed. The virtual prototype considers the Thermo-mechanical effects due to the joule effect induced by the power which crosses the DW and the Thermal contact ...

Methods to Optimize Plasmonic Structure Integrated Single-Photon Detector Designs - new

M. Csete[1], G. Szekeres[1], B. Banhelyi[2], A. Szenes[1], T. Csendes[2], G. Szabo[1]
[1]Department of Optics and Quantum Electronics, University of Szeged, Szeged, Hungary
[2]Department of Computational Optimization, University of Szeged, Szeged, Hungary

Introduction: Predesigned plasmonic structures are capable of enhancing optical phenomena, the key concept is tailoring the integrated devices' composition to engineer the spectral response and near-field distribution [1]. Our previous studies have shown that three-quarter-wavelength periodic plasmonic structures are capable of improving single-photon detection efficiency [2, 3]. Parametric sweep ...

Numerical Simulation of the Heat, Mass, and Momentum Transfer During the Microwave Drying of Osmodehydrated Porous Material - new

J. R. Arballo[1, 2], L. A. Campañone[1, 2], R. H. Mascheroni[1, 2]
[1]Universidad Nacional de La Plata (UNLP), La Plata, Buenos Aires, Argentina
[2]Centro de Investigación y Desarrollo en Criotecnología de Alimentos (CIDCA), La Plata, Buenos Aires, Argentina

Recent studies have been devoted to develop mathematical models to simulate the food processing using the porous media approach. The aim of this study is to simulate the microwave drying of osmodehydrated food by means of modeling the mass, energy and momentum transfer using the porous media approach. Microwave drying involves complex physical mechanisms which should be taken into account in the ...

Studying Crosstalk Trends for Signal Integrity on Interconnects using Finite Element Modeling

J. Grover[1], Dr. A. Gupta[1]
[1]Birla Institute of Technology and Science, Pilani-Pilani Campus,Rajasthan ,India

In high-speed digital design, strong electromagnetic coupling exists between adjacent transmission lines. This manifests itself in the form of crosstalk voltage induced on either line. Crosstalk is modeled in terms of capacitance and inductance matrices which are extracted using COMSOL Multiphysics®. Further, trends of crosstalk are observed with variations in dielectric constant of substrate, ...

Simulation of Light Coupling Reciprocity for a Photonic Grating

V. Kivijärvi[1], M. Erdmanis[1], I. Tittonen[1]
[1]Aalto University, Department of Micro- and Nanosciences, Espoo, Finland

SOI (Silicon on Insulator) technology utilizes silicon components on SiO2 layer. Propagating electric field distribution in a SOI waveguide is called mode of the waveguide. Photonic gratings are formed by etching grooves on the top of a waveguide. Gratings can operate in two directions. They can guide incident beam into a waveguide or a waveguide mode out of the structure. We study the grating ...
