Image Gallery

Welcome to the COMSOL Image Gallery. The simulation images on this page are available for editors and journalists to use in appropriate articles. The phrase "Image made using COMSOL Multiphysics® software and provided courtesy of COMSOL." must appear in the vicinity of every image or at the bottom of the article.

For all other uses you must contact COMSOL directly through www.comsol.com/contact/
or by writing to .

COMSOL Version 5.5

	Block Pressing on Arch A solid block pressing against an arch that is modeled using shell elements. block-pressing-arch.png - 111 KB
	Context Menu Graphics Window A context window is available by right-clicking in the Graphics window, to add boundary conditions more easily. context-menu-graphics-window.png - 173 KB
	Elastic Roller Chain Sprocket Model Model of an elastic roller chain sprocket assembly where one sprocket is driving another sprocket that has an external load. Results show the stress in the sprockets (color and contour plot), stress in the links (color plot), and link velocity (arrow plot) at a particular instance. elastic-roller-chain-sprocket-model.png - 434 KB
	Orbital Angular Momentum Beam A Laguerre Gaussian beam modeled with the Beam Envelopes method, using the unidirectional wave formulation. The input beam is a focusing Gaussian beam with a spiral phase distribution. orbital-angular-momentum-beam-model.jpg - 87 KB
	SAR computation in a human head SAR computation in a human head next to a Wi-Fi Antenna. sar-human-head-antenna.png - 627 KB
	Thermal Distribution Energy Pack The temperature distribution in a 6s2p battery pack at the end of a 4C discharge. thermal-distribution-battery-pack-comsol.png - 360 KB
	Parametric Sketching with Dimensions Parametric optimization of fluid flow in a microvalve using the sketching tool with dimensions and constraints capabilities available in the Design Module. dimensions-constraints-parameter-optimization.PNG - 345 KB tesla3.png - 161 KB
	Solver Technology for Acoustics Simulations Sound pressure field in a car interior solved with the finite element method at 7 kHz using a specialized solver for wave propagation analysis. car_cabin_acoustics_tweeter_in_dashboard_at_7kHz.png - 5.6 MB car_interior_7kHz_1_nogrid2.png - 268 KB
	Metal Processing Module Residual stresses in a spur gear after quenching, calculated using the Metal Processing Module. spurgear-quench-comsol-multiphysics.PNG - 159 KB
	Porous Media Flow Module Simulation of a packed bed latent heat storage tank, using the Porous Media Flow Module. thermal_storage_1b.png - 231 KB
	Shape and Topology Optimization Shape optimization of a sheet metal bracket using the Optimization Module. The structure is subjected to a bending load resulting in ridges in the optimal design. shell_shape_optimization_17.png - 331 KB
	Elastic Chain Drive Analysis Elastic chain drive analysis in the Multibody Dynamics Module. Colors and arrows show the velocity and velocity direction, in the chain and sprockets. chain_drive_velocity_gui_2.png - 169 KB
	COMSOL Runtime™ Installer The COMSOL Runtime™ installer for efficient distribution of standalone applications created with the Application Builder and compiled with COMSOL Compiler™. runtime_installer_5.png - 31 KB

Corrosion Module

Internal Pipeline Corrosion Protection Pipe potential in a piping system that is protected by sacrificial anodes. The red areas indicate the highest potentials, revealing the least protected parts. internal-pipeline-corrosion-protection-comsol.png - 438 KB

AC/DC Module

Multi-Turn Coil Winding Around a Ferromagnet A model of a 50 Hz AC coil wound around a ferromagnetic (linear) core. The model shows how to create a relatively complex geometry and set up the Multi-Turn Coil features for the simulation. multi-turn-coil-ferromagnet.png - 3.0 MB

Semiconductor Module

Nanowire Density Gradient Results showing the electron concentration (slices), current density (arrows), and electric potential (isosurfaces) from the new 3D Density-Gradient Simulation of a Nanowire MOSFET model. nanowire_density_gradient_3d_movie_.gif - 4.0 MB

Metal Processing Module

Spur Gear Quenching A spur gear after quenching that shows the phase fractions of austenite in blue and martensite in red. Modeled using the Metal Processing Module, an add-on to COMSOL Multiphysics. spur-gear-quenching.png - 632 KB

Composite Materials Module

Stress and Modal Analysis of a Composite Wheel Rim Model of a composite wheel rim made up of a carbon-epoxy material with a different number of layers in the rim and spokes. The results show the stress distribution in the wheel rim for specified inflation pressure and tire load. composite_wheel_rim.png - 1.6 MB
