放大电路中的电感器

Application ID: 990


本例显示如何将电子电路与有限元模拟组合起来。有限元模型是一个有非线性磁芯和 1000 匝的电感器,其中匝数采用分布电流技术来简化模拟。\n电路通过 SPICE 网链导入到 COMSOL Multiphysics,以常微分方程形式的电路单元与电感器模型耦合。

This model is included as an example in the following products:

AC/DC 模块

The combination of COMSOL® products required to model your application depends on several factors and may include boundary conditions, material properties, physics interfaces, and part libraries. Particular functionality may be common to several products. To determine the right combination of products for your modeling needs, review the 技术规格表 and make use of a free evaluation license. The COMSOL Sales and Support teams are available for answering any questions you may have regarding this.
